LY25-5R Wire And Cable Stripper With Cutting Blade 8-28mm

Market Price: 2

Wholesale Price:$ 1.60

Cable stripper, also known as cable cut or wire stripper, is used to peel off cable insulation. According to its different structure, it can be divided into simple type and ratchet type.
The simple type is composed of plastic shell and hardware accessories, which is used for temporary peeling in engineering. Its usage principle is: the push rod fastens the wire forward, and then uses the built-in blade to cut the insulation skin horizontally and longitudinally;
Ratchet structure is more complex, and it is suitable for large square cable. The ratchet and handle are used to clamp the cable, and then the blade with adjustable depth is used to cut the insulating skin in any direction;
LY25-5 wire stripper , red, is a simple type, with cutting blade and peeling diameter range is 8-28mm ;
LY25-5R cable stripper is easy to operate ;
LY25-5 cable pliers has a built-in screw cap for cutting depth adjustment, which can be adjusted according to the needs ;
According to the applicable diameter range or style, there are six types of simple insulation stripper: LY25-1R , LY25-2R , LY25-3R , LY25-4R , LY25-5R and LY25-6R ;
The simple Skinner has the characteristics of low price, easy to carry and strong applicability, but it is not recommended to buy if the quality requirements are too high ;

点击购买

Usage
Push the handle forward to clamp the cable body, adjust the depth of the cutter head, insert the insulation layer and peel it horizontally and vertically to remove the cable

Basic description
Name: Cable Stripper
Model: LY25-5R
Color: Red
Material: engineering plastics
Stripping range: diameter 8-28mm
Length : 130 mm
Weight: 0.15 kg/pcs
Package: foam shell + plug card
Function: suitable for stripping circular cable insulation layer within the corresponding diameter range

Product characteristics
Built in adjustable screw to adjust cutting depth
The rotary blade can realize vertical and horizontal peeling
The cable can be fixed by built-in spring
Antiskid material can avoid accidents during operation
